  • Replace brand: HYDAC
  • SKU: 0060D003BH3HC
  • Type: Filter element
  • Material: Fiberglass
  • Bluate No.: BLU-HD-W-04
SKU: 0060D003BH3HC Category:


Contact us and you will be satisfied with the discount (0060D003BH3HC)!

[Good price]

Our goods can be shipped anywhere in the world!
Place of Origin China
Certification ISO 9001:2015
Type Hydraulic Filter ElementĀ / Pressure Line
Structure Perforated support + Pleated Microglass
Seal Material Buna (Nitrile)
Total Height 3.31 inches
Diameter of top 1.875 inches
Diameter of bottom 1.875 inches
Filtration accuracy 3 microns
Maximum Pressure Differential 3045 Psi
Filter direction FOTI (Outside-In)
Operating Temp Min F -45F
Operating Temp Max F 245F
Minimum Order Quantity 1
Packaging Details Wooden box + carton + moisture-proof bag
Application field Lubricating oil and hydraulic oil system
Packaging pcs 1
Packaging L x W x H 2 inches x 2 inches x 4 inches

Inner diameter: 0.875 inches.

1.0060D003BH3HC replacement filter element adopts high-quality imported glass fiber or stainless steel mesh. Reasonable pleated structure makes it have a large circulation area. Moreover, its pressure loss is small, and it can maintain high-efficiency work stably for a long time.
2. This replacement filter element is generally used for hydraulic oil filtration. The filter element can also be used to filter hydraulic oil, water glycol, diesel, process fluids, lubricating oils, coolants, gasoline, process fluids, turbine and compressor oils, synthetic oils, and many more chemicals.
